Droplet Deformation and Stress Analysis Software
A laboratory engineering workflow needed to capture droplet deformation, extract reliable contours, and turn image sequences into repeatable measurements and stress-analysis records.
Convert fast, irregular visual behavior into comparable measurements
Lighting, focus, injection timing, camera exposure, background, contour quality, frame rate, and physical assumptions all affect whether the result is scientifically useful.
- Project focus
- droplet deformation analysis software
- Delivery scope
- Experiment capture + Contour analysis
- Operating goal
- Consistent acquisition
The model was only one part of the operating system
- 01
Synchronize injection and high-speed image capture
- 02
Segment the droplet boundary across changing shapes
- 03
Reject poor frames and preserve analysis parameters
- 04
Connect deformation measurements to an explicit stress model
Link acquisition, computer vision, calculation, and experiment records
ZedIoT built the camera-control workflow, image preprocessing, contour extraction, deformation metrics, stress calculation, visualization, recording, and export around repeatable experiments.
Experiment capture
Camera, lighting, timing, exposure, and metadata are controlled together.
Contour analysis
Image processing identifies the droplet boundary and flags low-quality frames.
Physical calculation
Versioned equations convert measured deformation into the required stress indicators.
Research records
Raw references, parameters, plots, results, and exports remain associated.
From image sequence to traceable analysis
Capture
The experiment produces synchronized, metadata-rich image frames.
Segment
The software extracts and validates each droplet contour.
Calculate
Deformation features feed the selected physical model.
Compare
Researchers review plots, records, and exported result sets.
A repeatable analysis workflow instead of manual frame inspection
The software brought camera operation, visual processing, calculation, and experiment records into one controlled workflow for continued laboratory validation.
Consistent acquisition
Camera and experiment parameters were recorded with each analysis run.
Reviewable contours
Researchers could inspect segmentation quality instead of accepting opaque calculations.
Comparable results
Deformation and stress outputs could be plotted and exported across experiments.
Scientific accuracy depends on validated optics, calibration, physical assumptions, reference measurements, and domain-expert review of the calculation model.
